In the last days I have put a new server for infrastructure services into operation at home.
It does not run as router or firewall, but has an SSHd for remote logins, DHCP and RADIUS server, DNS resolver, and cron jobs to do all those little things that must be done when my outer IP(v4) address changes, like updating dynamic DNS and reconfiguring the IPv6 tunnel with HE. For a few hours now,
has also been successfully blocking those pesky brute-force ssh attacks from China and the like.
The hardware is a small and — moderately — low power model from PC Engines, but still with a dual-core 1 GHz AMD CPU (amd64) and 4 GB of RAM, so it is quite capable. I have put in an SLC SSD (relatively expensive, but AIUI not as easily worn out by writing), also with 4 GB, which is enough for normal operation.http://www.pcengines.ch/apu1c4.htm
Despite being low power (≤ 12 W), that little thing runs quite hot. Internally, CPU and south bridge are thermally connected to the case via an aluminium heat spreader:http://www.pcengines.ch/apucool.htm
Still, the case gets so hot that I felt another cooling element is in order, as it is already quite warm on the upper boards of the store-room shelf (the left one in the picture):
With that, it runs up to 72 °C on the CPU when it is around 30 °C outside. As the CPU is rated for up to 90 °C, that seems to be okay.
The server is connected to my "core" network, to the WLAN segment, and to the DMZ, where incoming SSH connections are terminated.
As it runs security-critical services, I decided to give OpenBSD a try, for the first time. Not a bad idea — while not as much pre-packaged software is available as for, say, FreeBSD or Debian, most things I want are there, and then I should still be able to install most things from source. Or write them myself, dammit!
OpenBSD feels more like a "traditional" BSD than FreeBSD — the installation is rather like that of other systems 20 years ago; the whole setup feels simpler, more straightforward, with fewer automatic tentacles; updates are done by getting the source for the whole system
and recompiling. Without being able to give really informed comments yet, I can say it feels good, solid, familiar, definitely likeable.
BTW, the 4 GB SSD proved to be too small for rebuilding the system, so I had to put
on the file server, NFS-mounted over mere Fast Ethernet. I was afraid that this would slow down the system building by much, but building the userland was done after 5h20m, with 63% CPU utilization. Pleasant surprise!Update:
I have to admit that after some time I fell back to FreeBSD for this machine. While that decreases the OS diversity, it is much easier to update two FreeBSD boxen than one FreeBSD and one OpenBSD box. Also, the tunnel isn't to HE any more, but to my own external server, which is much closer, roundtrip-wise, and handled directly by the router (the middle device in the picture) using OpenVPN.
